IRF7425TRPBF Infineon Technologies IRF7425TRPBF Real Image1 IRF7425TRPBF Real Image2 IRF7425TRPBF real image
Same model may have multiple batches, images only for reference.
IRF7425TRPBF Infineon Technologies IRF7425TRPBF Real Image1 IRF7425TRPBF Real Image2 IRF7425TRPBF real image
IRF7425TRPBF Infineon Technologies IRF7425TRPBF Real Image1 IRF7425TRPBF Real Image2 IRF7425TRPBF real image
Same model may have multiple batches, images only for reference.

IRF7425TRPBF

Part No IRF7425TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH Si 20V 15A 8-Pin SOIC T/R / MOSFET P-CH 20V 15A 8-SOIC
Datasheet
IRF7425TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 15A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.2V @ 250μA
Max Gate Charge 130nC @ 4.5V
Max Input Capacitance 7980pF @ 15V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 2.5W (Ta)
Maximum Rds On at Id,Vgs 8.2 mOhm @ 15A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Dimension 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 100313-IRF7425TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IRF7425
Introduction Date February 09, 2006
ECCN EAR99
Country of Origin Malaysia, Mexico, Philippines, Taiwan, Thailand
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian IRF7425TRPBF CAD Model

Description

The Infineon Technologies 100313-IRF7425TRPBF is a P-Channel MOSFET with a drain-source breakdown voltage of 20V and a continuous drain current of 15A @ 25°C.

  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current: 15A @ 25°C
  • Maximum Rds On: 8.2 mOhm @ 15A and 4.5V
  • Maximum Gate Charge: 130nC @ 4.5V
  • Maximum Gate-Source Voltage: ±12V
  • Gate-Source Threshold Voltage: 1.2V @ 250μA
  • Maximum Input Capacitance: 7980pF @ 15V
  • Technology: SMD (SMT)
  • Category: Discrete Semiconductor Products
  • Commonly Used: Yes
  • Supply and Demand Status: Limited
