IRF8313PBF Real Image IRF8313PBF Real Image
Same model may have multiple batches, images only for reference.
IRF8313PBF Real Image IRF8313PBF Real Image
IRF8313PBF Real Image IRF8313PBF Real Image
Same model may have multiple batches, images only for reference.

IRF8313PBF

Part No IRF8313PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 30V 9.7A 8-SOIC
Datasheet
IRF8313PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 9.7A
Maximum Rds On at Id,Vgs 15.5 mOhm @ 9.7A, 10V
Gate-Source Threshold Voltage 2.35V @ 25μA
Max Gate Charge 90nC @ 4.5V
Max Input Capacitance 760pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 069413-IRF8313PBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF8313PBF CAD Model

Description

The Infineon Technologies IRF8313PBF is a dual N-Channel MOSFET with logic level gate feature.

  • Designed for: Use in power management applications
  • Continuous Drain Current @ 25°C: 9.7A
  • Maximum Rds On @ Id,Vgs: 15.5 mOhm @ 9.7A, 10V
  • Gate-Source Threshold Voltage: 2.35V @ 25μA
  • Maximum Gate Charge: 90nC @ 4.5V
  • Package: 8-SO
  • Maximum Input Capacitance: 760pF @ 15V
  • Supply and Demand Status: Limited
