IRFI3205PBF Infineon Technologies IRFI3205PBF real image
Same model may have multiple batches, images only for reference.
IRFI3205PBF Infineon Technologies IRFI3205PBF real image
IRFI3205PBF Infineon Technologies IRFI3205PBF real image
Same model may have multiple batches, images only for reference.

IRFI3205PBF

Part No IRFI3205PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 55V 64A TO220FP
Datasheet
IRFI3205PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 55V
Continuous Drain Current at 25°C 64A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 170nC @ 10V
Max Input Capacitance 4000pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 63W (Tc)
Maximum Rds On at Id,Vgs 8 mOhm @ 34A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB Full-Pak
Dimension TO-220-3 Full Pack
Win Source Part Number 1046923-IRFI3205PBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFI3205PBF CAD Model

Description

The IRFI3205PBF is a MOSFET technology electronic component from Infineon Technologies that is designed for use in discrete semiconductor products.

  • Polarity: N-channel
  • Maximum Power Dissipation: 63W (Tc)
  • Drain-Source Breakdown Voltage: 55V
  • Continuous Drain Current: 64A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate Charge: 170nC @ 10V
  • Maximum Input Capacitance: 4000pF @ 25V
  • Maximum Rds On @ Id,Vgs: 8 mOhm @ 34A, 10V
  • Package: TO-220AB Full-Pak
  • Dimension: TO-220-3 Full Pack
  • Mounting: Through hole
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Status: Active
  • Temperature Range: -55°C to 175°C (TJ)
  • Supply and Demand Status: Balanced
