IRL7833SPBF Infineon Technologies IRL7833SPBF Real Image IRL7833SPBF real image
Same model may have multiple batches, images only for reference.
IRL7833SPBF Infineon Technologies IRL7833SPBF Real Image IRL7833SPBF real image
IRL7833SPBF Infineon Technologies IRL7833SPBF Real Image IRL7833SPBF real image
Same model may have multiple batches, images only for reference.

IRL7833SPBF

Part No IRL7833SPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 30V 150A 3-Pin(2+Tab) D2PAK Tube / MOSFET N-CH 30V 150A D2PAK
Datasheet
IRL7833SPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 150A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.3V @ 250μA
Max Gate Charge 47nC @ 4.5V
Max Input Capacitance 4170pF @ 15V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 140W (Tc)
Maximum Rds On at Id,Vgs 3.8 mOhm @ 38A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 205474-IRL7833SPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IRL7833S
Introduction Date May 18, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian IRL7833SPBF CAD Model

Description

The Infineon Technologies IRL7833SPBF is an N-Channel MOSFET with a maximum power dissipation of 140W (Tc).

  • Maximum Power Dissipation: 140W (Tc)
  • Family: IRL7833S
  • Category: Discrete Semiconductor Products
  • Supply and Demand Status: limited
