The ICS843251AG-04LF is a high-performance, low-skew, zero delay buffer from Integrated Circuit Systems (now Renesas). It's designed to distribute clock signals with minimal added jitter and skew, making it suitable for use in high-speed digital systems where timing accuracy is critical.

Applications

• Clock Distribution Networks
• Server Motherboards
• Networking Equipment
• Data Centers
• High-Speed Digital Systems

Features

• Zero Delay Buffer: Provides minimal delay between input and output clocks.
• Low Skew: Ensures that all output clocks are synchronized with minimal timing differences.
• Low Jitter: Minimizes timing variations in the output clocks.
• Multiple Outputs: Distributes the clock signal to multiple destinations.
• 3.3V Operation: Compatible with common logic levels.
• RoHS Compliant: Complies with environmental regulations.

Benefits

• Improved System Performance: Low skew and jitter ensure accurate timing, improving the overall performance of high-speed digital systems.
• Simplified Design: Zero delay simplifies timing design and reduces the need for compensation circuits.
• Reliable Operation: Robust design ensures long-term reliability.
• Compact Size: Small package allows for use in space-constrained applications.
• Environmentally Friendly: RoHS compliance ensures compliance with environmental regulations.

Technical Specifications (Typical):

• Input Frequency: Up to 200 MHz
• Output Frequency: Up to 200 MHz
• Supply Voltage: 3.3V ± 5%
• Output Skew:
• Output Jitter:
• Number of Outputs: 1 differential output pair.
• Operating Temperature: 0°C to +70°C
• Package: TSSOP-8

The ICS843251AG-04LF is a crucial component for maintaining timing integrity in high-speed digital systems. Its low skew, low jitter, and zero delay characteristics make it an excellent choice for clock distribution applications. Always consult the official datasheet for the most accurate and detailed specifications before using this component in a design. The '-04LF' suffix indicates a specific lead-free RoHS compliant package.
