5M570ZT100I5N 5M570ZT100I5N Real Image1 5M570ZT100I5N Real Image2 5M570ZT100I5N Real Image3 5M570ZT100I5N Real Image4 5M570ZT100I5N Real Image5
Same model may have multiple batches, images only for reference.
5M570ZT100I5N 5M570ZT100I5N Real Image1 5M570ZT100I5N Real Image2 5M570ZT100I5N Real Image3 5M570ZT100I5N Real Image4 5M570ZT100I5N Real Image5
5M570ZT100I5N 5M570ZT100I5N Real Image1 5M570ZT100I5N Real Image2 5M570ZT100I5N Real Image3 5M570ZT100I5N Real Image4 5M570ZT100I5N Real Image5
Same model may have multiple batches, images only for reference.

5M570ZT100I5N

Part No 5M570ZT100I5N
Manufacturer Intel
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 440MC 9NS 100TQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - CPLDs (Complex Programmable Logic Devices)
Mfr Intel
Series MAX® V
Package Tray
Product Status Active
Programmable Verified
Programmable Type In System Programmable
Delay Time tpd(1) Max 9 ns
Voltage Supply - Internal 1.71V ~ 1.89V
Number of Logic Elements/Blocks 570
Number of Macrocells 440
Number of I/O 74
Temperature Range - Operating -40°C ~ 100°C (TJ)
Mounting Type Surface Mount
Package / Case 100-TQFP
Supplier Device Package 100-TQFP (14x14)
Base Product Number 5M570Z
Standard Package 90 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 856779-5M570ZT100I5N
Ultra Librarian 3D Model Ultra Librarian 5M570ZT100I5N CAD Model

Description

The 856779-5M570ZT100I5N is an embedded complex programmable logic device (CPLD) from Intel's MAX V series.

  • I/O Pins: 74
  • Programmable Method: In-system programmable
  • Delay Time: Maximum 9 ns
  • Voltage Supply: 1.71V to 1.89V
  • Logic Elements/Blocks: 570
  • Macrocells: 440
  • Mounting: Surface mount
  • Package: 100-TQFP
  • Operating Temperature Range: -40°C to 100°C
  • ECCN: EAR99
  • REACH: Unaffected
