CA3260AEZ Real Image CA3260AEZ Real Image
Same model may have multiple batches, images only for reference.
CA3260AEZ Real Image CA3260AEZ Real Image
CA3260AEZ Real Image CA3260AEZ Real Image
Same model may have multiple batches, images only for reference.

CA3260AEZ

Part No CA3260AEZ
Manufacturer Intersil
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 4MHZ 8DIP
Datasheet
CA3260AEZ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 10 V/μs
Gain Bandwidth Product (GBP) 4MHz
Current - Input Bias 2pA
Voltage - Input Offset 2mV
Operating Supply Current 9mA
Channel Output Current 45mA
Supply Voltage - Operating 4 V to 16 V, ±2 V to 8 V
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 8-PDIP
Win Source Part Number 1027576-CA3260AEZ
Popularity Medium
Supply and Demand Status Balance
Quantity per package 50
Ultra Librarian 3D Model Ultra Librarian CA3260AEZ CAD Model

Description

The Intersil CA3260AEZ is a general-purpose amplifier that has two circuits.

  • Manufacturer: Intersil
  • Type: General-Purpose Amplifier
  • Circuits: 2
  • Mounting: Through-Hole
  • Temperature Range: -55°C to 125°C
  • Slew Rate: 10 V/μs
  • Current-Input Bias: 2pA
  • Voltage-Input Offset: 2mV
  • Gain Bandwidth Product (GBP): 4MHz
  • Package: 8-PDIP
  • Supply Voltage Range: 4 V to 16 V, ±2 V to 8 V
  • Operating Supply Current: 9mA
  • Channel Output Current: 45mA
  • Alternative Parts: TLC082IP, UPC4572C-A, CA3260EZ
