ISL8499IRZ-T Intersil ISL8499IRZ-T Real Image
Same model may have multiple batches, images only for reference.
ISL8499IRZ-T Intersil ISL8499IRZ-T Real Image
ISL8499IRZ-T Intersil ISL8499IRZ-T Real Image
Same model may have multiple batches, images only for reference.

ISL8499IRZ-T

Part No ISL8499IRZ-T
Manufacturer Intersil
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH QUAD SPDT 16QFN
Datasheet
ISL8499IRZ-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Obsolete(EOL)
Switch Circuit SPDT
Number of Circuits 4
Max On Resistance 250 mOhm
Channel-to-Channel Matching (ΔRon) 40 mOhm
Single Supply Voltage (V+) 1.65 V to 4.5 V
Max Switch Time (Ton,Toff) 25ns, 23ns
Charge Injection -120pC
Channel Capacitance(CS off, CD off) 106pF
Max Leakage Current (IS off) 50nA
Crosstalk -98dB @ 100kHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-QFN (3x3)
Win Source Part Number 098772-ISL8499IRZ-T
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian ISL8499IRZ-T CAD Model

Description

The Intersil ISL8499IRZ-T is an obsolete (EOL) integrated circuit with four circuits and a switch circuit of SPDT.

  • Charge injection: -120pC
  • Crosstalk: -98dB @ 100kHz
  • Channel-to-channel matching (ΔRon): 40 mOhm
  • Supply and demand status: sufficient
  • Single supply voltage (V+): 1.65 V to 4.5 V
  • Dual supply voltage (V±): -
  • Max switch time (Ton,Toff): 25ns, 23ns
  • Channel capacitance (CS off, CD off): 106pF
  • Max leakage current (IS off): 50nA
  • Manufacturer: Intersil
  • Win Source Part Number: 098772-ISL8499IRZ-T
