The LRC-LRZ2010-R000 is a precision current sense resistor manufactured by IRC - a TT electronics Company. This resistor is designed for accurate current sensing in electronic circuits, providing a voltage output proportional to the current flowing through it. The low resistance value minimizes power loss and ensures minimal impact on the circuit's performance. It is commonly used in power supplies, motor control circuits, and other applications requiring accurate current measurement.

Applications

• Current sensing in power supplies
• Motor control circuits
• Overcurrent protection
• Feedback control systems
• Battery management systems

Features

• Low resistance value
• High precision
• Low temperature coefficient of resistance (TCR)
• Surface mount package
• RoHS compliant

Benefits

• Accurate Current Measurement: Provides precise current sensing for accurate monitoring and control of electronic circuits.
• Minimal Power Loss: Low resistance value minimizes power dissipation, improving efficiency.
• Stable Performance: Low TCR ensures stable resistance value over a wide temperature range.
• Easy Integration: Surface mount package allows for easy and reliable assembly.
• Environmentally Friendly: RoHS compliance ensures adherence to environmental regulations.

Additional Details

The LRC-LRZ2010-R000 is typically available in a 2010 surface mount package. The resistance value is very low, typically in the milliohm range. The specific resistance value, tolerance, and TCR should be verified in the product datasheet. This current sense resistor is designed for high-performance applications requiring accurate and reliable current measurement.
