SFH617A-2XSM Real Image
Same model may have multiple batches, images only for reference.

SFH617A-2XSM

Part No SFH617A-2XSM
Manufacturer Isocom Components 2004 LTD
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 5.3KV TRANS 4SMD  /  Optoisolator Transistor Output 5300Vrms 1 Channel
Datasheet
SFH617A-2XSM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators>Optoisolators - Transistor, Photovoltaic Output
Mfr Isocom Components 2004 LTD
Package Tube
Number of Channels 1
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 63% @ 10mA
Current Transfer Ratio (Max) 125% @ 10mA
Rise / Fall Time (Typ) 4µs, 3µs
Input Type DC
Output Type Transistor
Voltage - Output (Max) 70V
Current - Output / Channel 50mA
Voltage - Forward (Vf) (Typ) 1.65V (Max)
Current - DC Forward (If) (Max) 50 mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -30°C ~ 100°C
Mounting SMD (SMT)
Package / Case 6-SMD, Gull Wing
Base Product Number SFH617
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Standard Package 2,000
Win Source Part Number 1092461-SFH617A-2XSM
Ultra Librarian 3D Model Ultra Librarian SFH617A-2XSM CAD Model

Description

The SFH617A-2XSM is an optoisolator with a transistor photovoltaic output.

  • Component: SFH617A-2XSM
  • Type: optoisolator with a transistor photovoltaic output
  • Design: designed to provide electrical isolation between input and output circuits
  • Output Type: transistor
  • Input Type: DC
  • Maximum DC Forward Current: 50mA
  • Typical Forward Voltage: 1.65V (max)
  • Rise/Fall Time: 4/3µs
  • Output Current/Channel: 50mA
  • Number of Channels: 1
  • Voltage Isolation: 5300Vrms
  • Minimum Current Transfer Ratio: 63% @ 10mA
  • Maximum Current Transfer Ratio: 125% @ 10mA
  • Maximum Output Voltage: 70V
  • Vce Saturation: 400mV
  • Package/Case: 6-SMD, Gull Wing package/case
  • Temperature Range for Operation: -30°C to 100°C
  • ECCN: EAR99
  • REACH: unaffected by REACH
  • Manufacturer: Isocom Components 2004 LTD
