Same model may have multiple batches, images only for reference.

IXTT360N055T2

Name: IXTT360N055T2
Brand: IXYS
SKU: 1341233
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	IXTT360N055T2
Manufacturer	IXYS
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 55V 360A TO268 / N-Channel 55 V 360A (Tc) 935W (Tc) Surface Mount TO-268AA
Datasheet	IXTT360N055T2 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	IXYS
Series	TrenchT2™
Package	Tube
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	55 V
Current - Continuous Drain (Id) @ 25°C	360A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	2.4mOhm @ 100A, 10V
Vgs(th) (Max) @ Id	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	330 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	20000 pF @ 25 V
Power Dissipation (Max)	935W (Tc)
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	TO-268AA
Package / Case	TO-268-3, D³Pak (2 Leads + Tab) , TO-268AA
Base Product Number	IXTT360
Standard Package	30
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
California Prop 65	Warning Information
Win Source Part Number	1341233-IXTT360N055T2
Ultra Librarian 3D Model	Ultra Librarian IXTT360N055T2 CAD Model

Alternative Products

Description

The IXTT360N055T2 is a N-Channel MOSFET (Metal Oxide) transistor from IXYS's TrenchT2™ series.

FET Type: N-Channel MOSFET
Technology: MOSFET (Metal Oxide)
Series: TrenchT2™
Voltage - Drain to Source (Vdss): 55 V
Power Dissipation (Max): 935W (Tc)
Mounting Type: Surface Mount
Package / Case: TO-268-3, D³Pak (2 Leads + Tab) , TO-268AA
Vgs (Max): ±20V
Operating Temperature: -55°C ~ 175°C (TJ)
Current - Continuous Drain (Id) @ 25°C: 360A (Tc)
Rds On (Max) @ Id, Vgs: 2.4mOhm @ 100A, 10V
Gate Charge (Qg) (Max) @ Vgs: 330 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 20000 pF @ 25 V
