IXTV102N20T Real Image
Same model may have multiple batches, images only for reference.

IXTV102N20T

Part No IXTV102N20T
Manufacturer IXYS
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 102A PLUS220 / N-Channel 200 V 102A (Tc) 750W (Tc) Through Hole PLUS220
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr IXYS
Series TrenchHV™
Package Tube
Product Status Obsolete
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 200 V
Current - Continuous Drain (Id) @ 25°C 102A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 23mOhm @ 500mA, 10V
Vgs(th) (Max) @ Id 4.5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs 114 nC @ 10 V
Vgs (Max) ±30V
Input Capacitance (Ciss) (Max) @ Vds 6800 pF @ 25 V
Power Dissipation (Max) 750W (Tc)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Supplier Device Package PLUS220
Package / Case TO-220-3, Short Tab
Base Product Number IXTV102
Standard Package 50
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 1346689-IXTV102N20T
Ultra Librarian 3D Model Ultra Librarian IXTV102N20T CAD Model

Description

The IXYS 1346689-IXTV102N20T is a N-channel MOSFET transistor. 1346689-IXTV102N20T IXYS.

  • Maximum Drain to Source Voltage: 200V
  • Continuous Drain Current: 102A
  • Rds On Resistance: 23mOhm @ 500mA and 10V
  • Maximum Power Dissipation: 750W @ Tc
  • Device Type: Through-hole
  • Package: TO-220-3, Short Tab
  • Gate Charge: 114 nC @ 10V
  • Input Capacitance: 6800 pF @ 25V
  • Operating Temperature Range: -55°C to 175°C (TJ)
  • Series: TrenchHV™
  • Status: Obsolete
