Same model may have multiple batches, images only for reference.

SMAJ16A

Name: SMAJ16A
Brand: Jinan Gude Electronic Device
SKU: 668567
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMAJ16A
Manufacturer	Jinan Gude Electronic Device
Catalog	TVS - Diodes
Description	SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Jinan Gude Electronic Device
Win Source Part Number	1251255-SMAJ16A
Manufacturer Homepage	www.jgd.com.cn
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	SMAJ16A
Introduction Date	June 01, 2005
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Package	Tape & Reel (TR)
Product Status	Active
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	16V
Voltage - Breakdown (Min)	17.8V
Voltage - Clamping (Max) @ Ipp	26V
Current - Peak Pulse (10/1000µs)	15.3A
Power - Peak Pulse	400W
Power Line Protection	No
Applications	General Purpose
Operating Temperature	-55°C ~ 150°C (TJ)
Grade	-
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Supplier Device Package	DO-214AC (SMA)
Voltage - Reverse Standoff (Typ)	16V (Max)
Voltage - Breakdown (Min)	18.75V
Current - Peak Pulse (10/1000µs)	15.4A
Operating Temperature	-65°C ~ 150°C (TA)
Supplier Device Package	DO-214AC
Operating Temperature	-65°C ~ 150°C (TJ)
Package	Cut Tape (CT)
Supplier Device Package	SMA
Ultra Librarian 3D Model	Ultra Librarian SMAJ16A CAD Model

Alternative Products

Description

The SMAJ16A is an electronic component manufactured by Jinan Gude Electronic Device.

Family: SMAJ16A family
Compliance: Halogen-free standards
Popularity Rate: High
Supply and Demand Status: Balanced
Estimated EOL Date: 2024
Manufactured In: China
ECCN: EAR99 compliant
Features: Alternative parts available for cross-reference
