Same model may have multiple batches, images only for reference.
B4PS-VH(LF)(SN) Real Image
Same model may have multiple batches, images only for reference.

B4PS-VH(LF)(SN)

Part No B4PS-VH(LF)(SN)
Manufacturer JST Sales America Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 4POS 3.96MM / Connector Header Through Hole, Right Angle 4 position 0.156" (3.96mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr JST Sales America Inc.
Series VH
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.156" (3.96mm)
Number of Positions 4
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 1 Wall
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Locking Ramp
Contact Length - Mating 0.303" (7.70mm)
Contact Length - Post 0.142" (3.60mm)
Insulation Height 0.335" (8.51mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA66), Nylon 6/6
Temperature Range - Operating -25°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Natural
Current Rating (Amps) 10A
Voltage Rating 250V
Base Product Number B4PS-VH
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 455-1650,(D)B4PS-VH(LF)(SN),B4PSVHLFSN
Standard Package 500
Win Source Part Number 1000087-B4PS-VH(LF)(SN)
Ultra Librarian 3D Model Ultra Librarian B4PS-VH(LF)(SN) CAD Model

Description

The VH series 4-position male pin header connector is a reliable and durable solution for connecting wires to a printed circuit board.

  • Positions: 4
  • Material: Brass
  • Voltage Rating: 250V
  • Mounting: Through-hole
  • Fastening Type: Locking Ramp
  • Shrouded: One Wall
  • Mounting Type: Right-Angle
  • Contact Material: Tin
  • Contact Length: 0.303 inches
  • Post Length: 0.142 inches
  • Temperature Range: -25°C to 85°C
  • Insulation Material: Polyamide (PA66) and Nylon 6/6
  • Application: Board to cable/wire
  • Pitch Mating: 0.156 inches (3.96mm)
  • Manufacturer: JST Sales America Inc.
