Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Relays>Signal Relays, Up to 2 Amps
Mfr KEMET
Series EE2
Package Tape & Reel
Product Status Not For New Designs
Mounting SMD (SMT)
Coil Voltage 12VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2 A
Switching Voltage 250VAC, 220VDC - Max
Coil Current 11.7 mA
Coil Type Non Latching
Termination Style Gull Wing
Must Operate Voltage 9 VDC
Must Release Voltage 1.2 VDC
Operate Time 2 ms
Release Time 1 ms
Temperature Range - Operating -40°C ~ 85°C
Contact Material Silver Alloy, Gold Alloy
Relay Type General Purpose
Coil Resistance 1.03 kOhms
Other Names 399-10997-2,399-10997-1,399-10997-6
Standard Package 500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0020
Win Source Part Number 1237283-EE2-12NU-L
Ultra Librarian 3D Model Ultra Librarian EE2-12NU-L CAD Model

Description

The KEMET EE2-12NU-L is a signal relay with a DPDT (2 Form C) contact form.

  • Contact Form: DPDT (2 Form C)
  • Contact Rating: 2A
  • Switching Voltage: 250VAC, 220VDC - Max
  • Coil Voltage: 12VDC
  • Coil Resistance: 1.03 kOhms
  • Operating Temperature Range: -40°C ~ 85°C
  • Mounting: Surface Mount
  • Series: EE2
  • Package: Tape and Reel
  • Termination Style: Gull Wing
  • ECCN: EAR99
  • REACH: REACH Unaffected
