GAL16V8D-25QJN real image4484
Same model may have multiple batches, images only for reference.

GAL16V8D-25QJN

Part No GAL16V8D-25QJN
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 8MC 25NS 20PLCC
Datasheet
GAL16V8D-25QJN Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Bulk
Status Obsolete(EOL)
Programmable Type EE PLD
Delay Time tpd(1) Max 25.0ns
Voltage Supply - Internal 4.75 V to 5.25 V
Number of Macrocells 8
Temperature Range - Operating 0°C to 75°C (TA)
Mounting SMD (SMT)
Case / Package 20-PLCC (9x9)
Win Source Part Number 136285-GAL16V8D-25QJN
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian GAL16V8D-25QJN CAD Model

Description

The GAL16V8D-25QJN is a product manufactured by Lattice Semiconductor Corporation.

  • Programmable Type: EE PLD
  • Delay Time tpd(1) max: 25.0ns
  • Number of Macrocells: 8
  • Internal Voltage Supply: 4.75V to 5.25V
  • Mounting Type: SMD (SMT)
  • I/Os: None
  • Status: Obsolete
  • Popularity: Medium
  • Application: Integrated Circuits
