The ISPLSI-8600V-125LB272 is an in-system programmable Complex Programmable Logic Device (CPLD) from Lattice Semiconductor. It's designed for high-performance, high-density logic applications, offering a flexible and efficient solution for implementing complex digital circuits. The device is characterized by its in-system programmability, allowing designers to easily update and modify designs without removing the device from the circuit board.

Applications

• Industrial control systems
• Networking equipment
• Telecommunications infrastructure
• Data processing systems
• Medical equipment
• Aerospace applications

Features

• High Density: Provides a large amount of programmable logic resources.
• In-System Programmability (ISP): Allows for easy design updates and modifications.
• High Performance: Delivers fast propagation delays and high system clock frequencies.
• Low Power Consumption: Offers efficient power management.
• Flexible Routing Architecture: Enables efficient routing of signals.
• 272-Pin LBGA Package: Provides a compact and robust mounting option.
• 125 MHz Operating Frequency: Supports high-speed applications.

Benefits

• Reduced Time-to-Market: In-system programmability allows for rapid prototyping and design iteration.
• Increased Design Flexibility: The flexible architecture allows for implementing a wide range of digital circuits.
• Improved System Performance: High-speed performance enhances the overall system capabilities.
• Lower Power Consumption: Reduces energy costs and extends battery life in portable applications.
• Simplified Design Process: User-friendly software tools support design entry, simulation, and programming.

Additional Details

The ISPLSI-8600V-125LB272 supports a wide range of I/O standards, enabling seamless integration with various system components. It operates over a wide voltage range, typically 3.3V or 5V, providing flexibility in power supply design. The device is supported by Lattice Semiconductor's design software, which provides a comprehensive suite of tools for developing and implementing complex logic designs. It is commonly used in applications requiring high-speed data processing, complex state machines, and custom logic functions. The 272-pin LBGA package ensures reliable connectivity and efficient heat dissipation. Lattice Semiconductor is a leading provider of programmable logic solutions.
