Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Amplifier Type Current Feedback
Number of Circuits 1
Slew Rate 900 V/μs
-3db Bandwidth 60MHz
Current - Input Bias 10μA
Voltage - Input Offset 3mV
Operating Supply Current 20mA
Channel Output Current 1.2A
Supply Voltage - Operating 10 V to 30 V, ±5 V to 15 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 125773-LT1206CS8#TRPBF
Ultra Librarian 3D Model Ultra Librarian LT1206CS8#TRPBF CAD Model

Description

LT1206CS8#TRPBF - High-Speed, High-Current Op Amp from Linear Technology

The LT1206CS8#TRPBF is a robust, high-speed, current feedback operational amplifier from Linear Technology, now part of Analog Devices. This high-performance op-amp is designed to excel in applications demanding fast and precise signal amplification with high output current capability. It is a perfect fit for video and cable driving, A/D buffer amplifiers, test equipment, and high-speed communications systems.

Key Features:

  • High Speed: With a slew rate of 600V/µs and a bandwidth of 60MHz when driving a 150Ω load, the LT1206CS8#TRPBF can handle fast signal transitions, making it ideal for high-speed data acquisition and video processing applications.
  • High Output Current: Capable of delivering up to 100mA of output current, this op-amp can drive heavy loads without significant signal degradation. This high current capability also makes it suitable for driving cables and other low-impedance loads.
  • Wide Supply Range: The device can operate from a supply range of ±4V to ±15V, providing flexibility in various supply environments.
  • Low Distortion: With low harmonic distortion characteristics, it ensures high-fidelity signal amplification, which is critical for audio and instrumentation applications.

Product Specifications:

Parameter Value Slew Rate 600V/µs Gain Bandwidth Product 60MHz Output Current 100mA Supply Voltage Range ±4V to ±15V Operating Temperature Range -40°C to 85°C

The LT1206CS8#TRPBF is packaged in an 8-lead SOIC package with a part number suffix indicating tape and reel packaging for automated assembly processes. Its combination of speed, power, and precision makes it a versatile choice for engineers and designers looking to enhance the performance of their high-speed analog circuits.
