The LT1963AEQ-1.8#TRPBF is a high-performance, low dropout linear regulator from Linear Technology that delivers a continuous output current of up to 1.5A with a dropout voltage of typically 340mV at full load. This regulator is designed for applications requiring low noise, fast transient response, and high power supply rejection ratio (PSRR).

Key Features

• Output Voltage: Fixed at 1.8V, providing a stable and precise voltage for critical applications.
• High Output Current: Capable of delivering 1.5A of continuous output current, making it suitable for powering a variety of loads.
• Low Dropout Voltage: A low dropout voltage of 340mV ensures efficient operation even when the input-to-output voltage differential is minimal.
• Excellent Noise Performance: With an output noise as low as 40μV RMS, this regulator is ideal for sensitive RF and analog circuitry.
• Fast Transient Response: The device's quick response to load changes makes it ideal for applications with varying load conditions.
• Stable with Low ESR Capacitors: The LT1963AEQ-1.8#TRPBF remains stable with ceramic, tantalum, or aluminum electrolytic capacitors, offering flexibility in design.
• Thermal Protection: Built-in thermal shutdown and current limit protections safeguard the device and the application from over-current and over-temperature conditions.

Applications

This regulator is well-suited for a range of applications, including:

• High-efficiency linear power supplies
• Post-regulation for switching supplies
• Battery-powered devices
• Microprocessor and logic supply
• Power management for notebooks and portable devices

Package and Availability

The LT1963AEQ-1.8#TRPBF comes in a 5-lead DDPAK/TO-263 package, which is designed for surface mount technology and is available in tape and reel packaging for automated assembly processes. This product is RoHS compliant and meets the requirements for lead-free and green product standards.
