Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage Input MAX 20V
Output Voltage 1.2V
Output Voltage MAX 19.5V
Voltage Dropout (Maximum) 0.49V @ 1.1A
Output Current 1.1A
Operating Supply Current 1.1mA ~ 40mA
PSRR 75dB (120Hz)
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity
Operating Temperature Range -40°C ~ 125°C
Mounting Style Through Hole
Package TO-220-5 Formed Leads
Manufacturer Package TO-220-5
Win Source Part Number 780807-LT1965IT#PBF
Popularity Medium
Supply and Demand Status Balance
Family Name LT1965
Introduction Date August 06, 2007
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LT1965IT#PBF CAD Model

Description

The LT1965IT#PBF is a high-performance low dropout linear regulator (LDO) from Linear Technology, now part of Analog Devices, designed to provide precision voltage regulation with a minimal noise footprint. This component is well-suited for applications requiring clean and stable power supply, including sensitive RF and audio circuits, as well as other critical systems.

Key Features:

  • Low Noise Output: With an output noise as low as 40µV RMS over a 10Hz to 100kHz bandwidth, the LT1965IT#PBF ensures a clean power supply, making it ideal for noise-sensitive applications.
  • High Output Current: Capable of delivering up to 1.1A of continuous output current, this LDO can power a wide range of devices.
  • Low Dropout Voltage: The device maintains regulation with a very low dropout voltage, typically 300mV at full load, which enhances efficiency and allows operation over a wider range of input voltages.
  • Adjustable Output: While it comes with fixed output voltage options, the LT1965IT#PBF also offers an adjustable output from 1.2V to 20V, providing flexibility for various design requirements.
  • Stable with Low ESR Capacitors: It remains stable with ceramic, tantalum, or aluminum electrolytic capacitors, reducing the need for additional components and simplifying design.
  • Overcurrent and Overtemperature Protection: Built-in protection mechanisms safeguard the device and the downstream circuitry from damage due to excessive current or overheating.

Applications:

  • High-end audio equipment
  • Precision data acquisition systems
  • RF applications
  • Medical equipment
  • Battery-powered devices
  • Portable instrumentation

The LT1965IT#PBF is available in a thermally efficient TSSOP-16 package, which allows for optimal heat dissipation and reliable operation even under high power conditions. With its robust design and versatile features, this LDO is a go-to choice for engineers seeking a high-quality power management solution.
