LT3462AES6#TRPBF - A High-Efficiency DC/DC Converter from Linear Technology

The LT3462AES6#TRPBF is a versatile and compact DC/DC converter integrated circuit from Linear Technology, designed to provide efficient power conversion in a wide range of applications. This device is particularly well-suited for portable and battery-powered equipment due to its low quiescent current and high efficiency over a broad load range.

Key Features:

• Adjustable Output Voltage: The output voltage can be adjusted to meet the requirements of various applications, providing design flexibility.
• Integrated Boost Converter: With an internal 1.3A, 40V switch, the LT3462AES6#TRPBF can step-up input voltages as low as 2.5V to a higher output voltage, which is essential for driving LEDs or other high-voltage loads.
• High Frequency Operation: The device operates at a switching frequency of 1.2MHz, allowing the use of small, low-cost capacitors and inductors, thus reducing the overall solution footprint.
• Low Quiescent Current: It features a low quiescent current of just 2.5µA, making it ideal for battery-powered applications where power conservation is critical.
• Thermal Protection: The LT3462AES6#TRPBF includes thermal shutdown functionality, providing additional protection and reliability under high-temperature conditions.

Applications:

• Portable and Battery-Powered Devices
• LED Drivers
• Handheld Medical Equipment
• Wireless Modems and Network Cards

This product comes in a small SOT-23 package, making it an excellent choice for space-constrained applications. The LT3462AES6#TRPBF is also available in tape and reel packaging (denoted by the 'TRPBF' suffix), which is suitable for automated manufacturing processes, ensuring efficient handling and placement during circuit board assembly.

Linear Technology, now part of Analog Devices, is renowned for its high-performance analog integrated circuits. The LT3462AES6#TRPBF is a testament to their commitment to quality, offering a reliable and high-efficiency solution for power conversion challenges.
