Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 3.6V
Maximum Input Voltage 36V
Nominal Output Voltage (Min/Fixed) 0.79V
Maximum Output Voltage 20V
Output Current 2A
Frequency - Switching 200kHz to 2.4MHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 1059550-LT3685IDD#TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT3685IDD#TRPBF CAD Model

Description

Product Overview: LT3685IDD#TRPBF

The LT3685IDD#TRPBF is a high-performance, adjustable frequency, 2A step-down switching regulator from Linear Technology. This compact and efficient integrated circuit is designed to meet the needs of a wide range of applications, including portable devices, automotive electronics, and industrial systems.

Key Features

  • Wide Input Voltage Range: Capable of operating from an input voltage range of 3.6V to 36V, making it suitable for applications with varying power supplies.
  • Adjustable Switching Frequency: The switching frequency can be adjusted from 300kHz to 2.5MHz, allowing designers to optimize performance for their specific application.
  • High Efficiency: Integrated 85mΩ switches deliver efficiencies up to 92%, reducing power loss and heat generation.
  • Low Dropout Operation: The regulator's low dropout performance ensures continued operation even as the input voltage approaches the output voltage.
  • Stable with Ceramic Capacitors: The LT3685IDD#TRPBF remains stable with ceramic output capacitors, which are smaller, more reliable, and have lower equivalent series resistance (ESR) than other types.

Protection Features

  • Overtemperature Protection: Protects the device from damage due to excessive heat.
  • Overcurrent Protection: Limits the output current to prevent damage to the regulator and the powered device in case of a short circuit or overload.
  • Undervoltage Lockout (UVLO): Ensures the regulator operates only when the input voltage is within a safe range.

Applications

The LT3685IDD#TRPBF's flexible design and robust feature set make it an ideal choice for a variety of applications, including:

  • Portable electronics such as laptops and tablets
  • Automotive power systems, including infotainment and navigation units
  • Industrial equipment that requires a stable and efficient power supply
  • Distributed power supply systems
  • Telecommunications infrastructure

Package and Quality

The LT3685IDD#TRPBF is available in a compact 10-lead DFN package with a thermal pad for enhanced thermal performance. Linear Technology ensures high-quality and reliability of its products, suitable for demanding environments.
