The LTC1386CS is a high-quality RS232 transceiver component from Linear Technology, designed to provide reliable bidirectional communication in applications requiring serial data exchange. This integrated circuit is part of Linear Technology's family of transceivers that are specifically tailored for RS232 and V.28 communication protocols.

Key Features

• Single 5V Power Supply: The LTC1386CS operates on a single 5V power supply, making it compatible with a wide range of standard digital logic levels and systems.
• Low Power Consumption: Designed for energy-efficient performance, this transceiver consumes low power, which is ideal for portable and battery-powered devices.
• On-Chip Charge Pumps: The device includes on-chip charge pumps that generate the necessary RS232 voltage levels (+/-10V) from a single 5V supply, thus eliminating the need for external components.
• High Data Rates: It supports data rates up to 120 kbps, allowing for fast data transmission that is suitable for a variety of communication applications.
• Multiple Drivers and Receivers: The LTC1386CS features three drivers and five receivers, providing the flexibility to interface with multiple RS232 connections.
• ESD Protection: It offers enhanced electrostatic discharge (ESD) protection for all pins, ensuring robust performance in environments prone to static electricity.

Applications

The LTC1386CS is versatile and can be used in a range of applications, such as:

• Portable Computing Devices
• Modems
• Networking Equipment
• Peripheral Interfaces
• Industrial Control Systems

Package and Reliability

The LTC1386CS is available in a 16-lead narrow SOIC package, which is suitable for space-constrained applications. Linear Technology ensures high reliability and performance of the LTC1386CS, making it a trusted choice for engineers and designers looking for a robust RS232 transceiver solution.
