Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Operating Supply Current 155μA
Operating Supply Voltage 2.7 V ~ 5.5 V
Mounting SMD
Package 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Manufacturer Package 8-MSOP
Win Source Part Number 782288-LTC1966IMS8#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTC1966
Introduction Date October 03, 2002
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTC1966IMS8#PBF CAD Model

Description

Linear Technology LTC1966IMS8#PBF Precision RMS-to-DC Converter

The LTC1966IMS8#PBF is a high-precision RMS-to-DC converter from Linear Technology, designed to deliver accurate and reliable performance for a wide range of applications. This device utilizes a patented delta-sigma conversion technique, providing a true RMS calculation over a wide bandwidth. The LTC1966IMS8#PBF is particularly well-suited for applications that require precise measurement of AC signals, including industrial controls, instrumentation, and communication systems.

Key Features:

  • High Accuracy: The LTC1966IMS8#PBF boasts outstanding accuracy and linearity, ensuring that RMS values are measured with precision, even with complex waveforms or noisy environments.
  • Wide Bandwidth: With a bandwidth of up to 1MHz, this RMS-to-DC converter can handle high-frequency signals, making it versatile for various applications.
  • Low Power Consumption: Designed for efficiency, the LTC1966IMS8#PBF consumes minimal power, an essential feature for battery-powered or energy-conscious designs.
  • Easy Integration: The compact MSOP-8 package allows for easy integration into existing circuit designs without requiring significant board space.
  • No External Trimming: The device requires no external trimming for most applications, which simplifies design and reduces time to market.
  • Temperature Stability: The LTC1966IMS8#PBF maintains its performance across a wide temperature range, ensuring reliable operation under varying environmental conditions.

Applications:

  • Power Management Systems
  • Signal Processing
  • Test and Measurement Equipment
  • Audio Analysis
  • Wireless Communications

The LTC1966IMS8#PBF provides a robust and precise RMS-to-DC conversion solution, making it a go-to choice for designers looking for high performance in a compact form factor. Whether you're developing sophisticated measurement equipment or working on audio signal processing, the LTC1966IMS8#PBF from Linear Technology will meet your needs with its exceptional precision and reliability.
