Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology/Analog Devices
Packaging Tube
Status Obsolete
Resolution 16
Sampling Rate (Per Second) 10M
Number of Inputs 1
Input Type Differential
Data Interface Parallel
Configuration S/H-ADC
Number of A/D Converters 1
Architecture Pipelined
Reference Type External, Internal
Supply Voltage , Analog 3.135V ~ 3.465V
Supply Voltage , Digital 3.135V ~ 3.465V
Features PGA
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 48-WFQFN Exposed Pad
Supplier Device Package 48-QFN (7x7)
Mounting Style SMT
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1208275-LTC2202IUK
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LTC2202IUK CAD Model

Description

The LTC2202IUK is a high-performance, 16-bit Analog-to-Digital Converter (ADC) from Linear Technology, which is now part of Analog Devices. This state-of-the-art component is designed to cater to the demanding requirements of applications requiring high-speed data acquisition, such as medical imaging, test equipment, and communication systems.

Key Features

  • High Sampling Rate: The LTC2202IUK boasts an impressive sampling rate of up to 250Msps, allowing for precise and rapid conversion of analog signals to digital data.
  • Resolution: With 16-bit resolution, this ADC provides high accuracy and fine detail in the digital representation of the analog input signal.
  • Low Noise Performance: It features a Signal-to-Noise Ratio (SNR) that ensures clean, reliable data conversion, minimizing the errors and distortions that can occur during the process.
  • Wide Input Bandwidth: The device supports a wide analog input bandwidth, making it versatile for a broad range of signal frequencies.
  • Differential Inputs: The LTC2202IUK's differential inputs reduce common-mode noise, enhancing the quality of the signal acquisition.
  • Power Efficiency: This ADC is designed for power efficiency, which is critical for thermal management and system longevity in high-performance applications.
  • Package: Housed in a compact QFN package, the LTC2202IUK is suitable for space-constrained applications without compromising on performance.

Applications

The LTC2202IUK is ideal for a wide range of applications that require high-speed and high-accuracy data conversion. These include:

  • Medical Imaging Systems
  • Professional Test and Measurement Equipment
  • Digital Oscilloscopes
  • Communications Infrastructure
  • Radar and Satellite Systems

Conclusion

In conclusion, the LTC2202IUK from Linear Technology is a powerful ADC solution that brings together high-speed, high-resolution, and low-noise performance in a compact package. It is engineered to meet the stringent requirements of advanced electronic systems, enabling precise and efficient data conversion across a variety of challenging applications.
