Products specifications

Manufacturer Linear Technology
Win Source Part Number 1209056-LTC4252-2IMS
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC4252-2IMS CAD Model

Description

LTC4252-2IMS Negative Voltage Hot Swap Controller

The LTC4252-2IMS is a sophisticated integrated circuit designed by Linear Technology, now part of Analog Devices, tailored for managing hot swap events in systems with negative supply voltages. This compact and efficient controller allows electronic circuit boards to be inserted into and removed from a live backplane without causing any disruption or damage to the electrical system.

Constructed with robustness in mind, the LTC4252-2IMS is encapsulated in a durable MSOP package, ensuring reliable performance in a variety of industrial and commercial applications. The device is specifically engineered to control the power supply during insertion and removal by limiting the inrush current, which can cause voltage disturbances and potential damage to connectors and circuit components.

Key features of the LTC4252-2IMS include:

  • Operation with supply voltages ranging from -9V to -80V, catering to a wide array of negative voltage systems.
  • An adjustable current limit that provides flexibility in managing the inrush current, enhancing the protection of the system components.
  • Overcurrent and overtemperature protection, which ensures safe operation under abnormal conditions by turning off the external N-channel MOSFET.
  • A gate charge pump that maintains the gate of the N-channel MOSFET above the source by a fixed voltage, ensuring reliable operation.
  • Undervoltage lockout (UVLO) feature that prevents the system from operating at dangerously low voltages, which could lead to erratic system behavior.

The LTC4252-2IMS also boasts a status output that indicates the presence of an overcurrent condition, providing diagnostic feedback that can be used for system monitoring and fault management. This feature is particularly useful for system administrators and engineers who need to maintain high system reliability and uptime.

Overall, the LTC4252-2IMS is an essential component for systems requiring secure and seamless hot swapping capabilities with negative voltages. Its combination of protection features, along with its robust design, makes it an ideal choice for telecommunications, data centers, and other critical electronic infrastructures.
