Linear Technology LTC6804IG-1 High Voltage Battery Monitor

The LTC6804IG-1 is a sophisticated battery monitoring IC developed by Linear Technology, designed to cater to the precise needs of high voltage battery management systems. This advanced product is an essential component for applications such as electric vehicles (EVs), hybrid electric vehicles (HEVs), and large-scale energy storage systems where accurate monitoring of multiple battery cells is critical for both performance and safety.

Key Features

• Multiple Cell Monitoring: The LTC6804IG-1 is capable of simultaneously measuring up to 12 individual battery cells with a total measurement error under 1.2mV.
• High Voltage Capability: This device can tolerate up to 1000V, making it suitable for high voltage battery stacks commonly found in electric vehicles and energy storage applications.
• Data Integrity: It includes a redundant data check feature, ensuring the integrity of the data through a 5th order polynomial error check code (PEC).
• Temperature Measurements: It can measure and report the temperature of the monitored cells, which is vital for managing the thermal conditions of the battery pack.
• Daisy Chain Configuration: The LTC6804IG-1 supports a daisy chain configuration, allowing multiple devices to be connected in series without the need for isolators, simplifying the design and reducing costs.
• Robust Communication: It uses an isolated SPI interface for robust communication in noisy environments.
• Compact Design: The device comes in a compact 44-lead SSOP package.

Applications

• Electric Vehicles (EVs)
• Hybrid Electric Vehicles (HEVs)
• Backup Power Systems
• Energy Storage Systems
• Uninterruptible Power Supplies (UPS)

The LTC6804IG-1 is not just a battery monitor; it is an integral solution for high reliability and performance in critical applications where battery system integrity is non-negotiable. With its high voltage tolerance and precision measurement capabilities, it stands as a cornerstone in the field of battery monitoring technology.
