0154.750DR Real Image 0154.750DR real image
Same model may have multiple batches, images only for reference.
0154.750DR Real Image 0154.750DR real image
0154.750DR Real Image 0154.750DR real image
Same model may have multiple batches, images only for reference.

0154.750DR

Part No 0154.750DR
Manufacturer Littelfuse Inc.
Catalog Fuses
Description FUSE BOARD MNT 750MA 125VAC/VDC
Datasheet
0154.750DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Packaging Reel
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 750mA
Voltage Rating - AC 125V
Voltage Rating - DC 125V
Response Time Fast Blow
Manufacturer Package 2-SMD, Square End Block with Holder
Mounting Style Holder, Surface Mount
Breaking Capacity at Rated Voltage 50A
Melting I2t 0.185
Approvals UL
Temperature Range - Operating -55°C ~ 125°C
Dimension 0.383" L x 0.198" W x 0.150" H (9.73mm x 5.03mm x 3.81mm)
DC Cold Resistance 0.245 Ohms
Manufacturer Pack Quantity 1,500
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 805170-0154.750DR
Ultra Librarian 3D Model Ultra Librarian 0154.750DR CAD Model

Description

The 805170-0154.750DR is a surface mount fuse component manufactured by Littelfuse Inc.

  • Supply and Demand: Balanced
  • Current Rating: 750mA
  • Breaking Capacity: 50A
