1812L020/60DR Real Image 1812L020/60DR real image
Same model may have multiple batches, images only for reference.
1812L020/60DR Real Image 1812L020/60DR real image
1812L020/60DR Real Image 1812L020/60DR real image
Same model may have multiple batches, images only for reference.

1812L020/60DR

Part No 1812L020/60DR
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 60V 200MA 1812
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel
Type Polymeric
Voltage - Max 60V
Current - Max 40A
Current - Hold (Ih) (Maximum) 200mA
Current - Trip (It) 400mA
Time to Trip 2s
Resistance - Initial (Ri) (Minimum) 1.4 Ohms
Resistance - Post Trip (R1) (Maximum) 4.4 Ohms
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 1812 (4532 Metric), Concave
Parts Dimension 0.179" L x 0.128" W (4.55mm x 3.24mm)
Thickness (Maximum) 0.049" (1.25mm)
Approvals cURus, TUV
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 713013-1812L020/60DR
Popularity Low
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 1812L020/60DR CAD Model

Description

Littelfuse Inc.'s 713013-1812L020/60DR is a polymeric positive temperature coefficient (PPTC) device that is designed for circuit protection.

  • Maximum voltage: 60V
  • Maximum current: 40A
  • Trip current: 400mA
  • Time to trip: 2s
  • Resistance: 1.4 Ohms
  • Post-trip resistance: 4.4 Ohms
