SRP200

Part No SRP200
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Datasheet
SRP200 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>PTC Resettable Fuses
Mfr Littelfuse Inc.
Series PolySwitch®, SRP
Package Bulk
Product Status Obsolete
Type Polymeric
Voltage - Max 30V
Current - Max 100 A
Current - Hold (Ih) (Max) 2 A
Current - Trip (It) 4.4 A
Time to Trip 4 s
Resistance - Initial (Ri) (Min) 30 mOhms
Resistance - Post Trip (R1) (Max) 100 mOhms
Temperature Range - Operating -40°C ~ 85°C
Mounting Type User Defined
Package / Case Strap
Dimension 0.880" L x 0.417" W (22.35mm x 10.60mm)
Thickness (Max) 0.043" (1.10mm)
Approval Agency CSA, TUV, UL
Other Names Q688881,Q494484
Standard Package 500
RoHS Status RoHS non-compliant
MSL Level 2A (4 Weeks)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
Win Source Part Number 1301589-SRP200
Ultra Librarian 3D Model Ultra Librarian SRP200 CAD Model

Description

The Littelfuse Inc. PolySwitch SRP200 is an obsolete PTC resettable fuse that offers a maximum voltage of 30V and a maximum current of 100A.

  • Time to Trip: 4 seconds
  • Operating Temperature Range: -40°C to 85°C
  • Package/Case: Strap
  • Resistance: 30 mOhms
