MX25R1635FM2IL0 Real Image MX25R1635FM2IL0 real image16890 MX25R1635FM2IL0 Real Image
Same model may have multiple batches, images only for reference.
MX25R1635FM2IL0 Real Image MX25R1635FM2IL0 real image16890 MX25R1635FM2IL0 Real Image
MX25R1635FM2IL0 Real Image MX25R1635FM2IL0 real image16890 MX25R1635FM2IL0 Real Image
Same model may have multiple batches, images only for reference.

MX25R1635FM2IL0

Part No MX25R1635FM2IL0
Manufacturer Macronix
Catalog Memory
Description IC FLASH 16MBIT SPI/QUAD 8SOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Memory - Memory
Mfr Macronix
Series MXSMIO™
Package Tube
Product Status Obsolete
Programmable Not Verified
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 16Mbit
Memory Organization 2M x 8
Memory Interface SPI - Quad I/O
Clock Frequency 33 MHz
Write Cycle Time - Word, Page 100µs, 10ms
Voltage - Supply 1.65V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209", 5.30mm Width)
Supplier Device Package 8-SOP
Base Product Number MX25R1635
Standard Package 92 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.32.0071
Win Source Part Number 852636-MX25R1635FM2IL0
Ultra Librarian 3D Model Ultra Librarian MX25R1635FM2IL0 CAD Model

Description

The MX25R1635FM2IL0 is a 16Mbit FLASH - NOR memory integrated circuit (IC) from Macronix.

  • Memory Type: Non-Volatile
  • Voltage Supply: 1.65V to 3.6V
  • Memory Organization: 2M x 8
  • Clock Frequency: 33 MHz
  • Mounting Type: Surface Mount
  • Package: 8-SOIC
  • Operating Temperature: -40°C to 85°C
  • Write Cycle Time (Word/Page): 100µs / 10ms
  • Memory Interface: SPI - Quad I/O
  • Series: MXSMIO™
  • Standard Package: 92 pcs
  • Status: Obsolete
  • ECCN: EAR99
