MAX15053EWL+T

Part No MAX15053EWL+T
Manufacturer Maxim Integrated
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BUCK ADJ 2A SYNC 9WLP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.7V
Maximum Input Voltage 5.5V
Nominal Output Voltage (Min/Fixed) 0.6V
Maximum Output Voltage 5.17V
Output Current 2A
Frequency - Switching 1MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 9-WLP (1.5x1.5)
Win Source Part Number 120133-MAX15053EWL+T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX15053EWL+T CAD Model

Description

The MAX15053EWL+T is a highly efficient, compact, synchronous step-down DC-DC converter from Maxim Integrated, a leader in analog and mixed-signal engineering. This power management integrated circuit (IC) is designed to deliver up to 2A of continuous output current with an input voltage range of 2.9V to 5.5V, making it an ideal solution for battery-powered devices and low-voltage power supplies.

Featuring an integrated high-side switch and synchronous rectifier, the MAX15053EWL+T minimizes the need for external components, thus reducing the overall solution size and cost. The device operates at a fixed 1MHz switching frequency, which allows for the use of small, low-profile inductors and capacitors, further saving board space and making it well-suited for space-constrained applications.

The MAX15053EWL+T boasts an impressive efficiency, which is maintained over a wide load range due to its low quiescent current and pulse-frequency modulation (PFM) mode at light loads. This feature extends battery life in portable devices, making it an excellent choice for handheld and wearable technology.

Additional features of the MAX15053EWL+T include internal soft-start to reduce inrush current during startup, thermal shutdown, and overcurrent protection to safeguard the device and the system it powers from damage due to excessive heat or load conditions. These protection features enhance the reliability and longevity of the end application.

The device is available in a tiny, lead-free 6-pin WLP (wafer-level package) with a 1.5mm x 1.0mm footprint, which is particularly beneficial for designs where space is at a premium. Its operating temperature range of -40°C to +85°C ensures stable performance across various environments and applications.

In summary, the MAX15053EWL+T from Maxim Integrated is a versatile, high-efficiency step-down converter that offers a compact solution for a wide range of power management applications. Its combination of performance, small size, and protective features makes it an excellent choice for designers looking to optimize their power supply designs for both space and efficiency.
