MAX4665ESE+T

Part No MAX4665ESE+T
Manufacturer Maxim Integrated
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH QUAD SPST 16SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Maxim Integrated
Packaging Reel - TR
Switch Circuit SPST - NO
Number of Circuits 4
On-State Resistance (Maximum) 4 Ohm
Channel-to-Channel Matching (ΔRon) 200 mOhm
Operating Supply Voltage 4.5 V ~ 36 V
Dual Voltage Supply ±4.5 V ~ 20 V
Switch Time (Ton, Toff) (Maximum) 275ns, 175ns
Charge Injection 300pC
Channel Capacitance (CS(off), CD(off)) 34pF, 34pF
Current - Leakage (IS(off)) (Maximum) 500pA
Crosstalk -60dB @ 1MHz
Operating Temperature Range -40°C ~ 85°C (TA)
Package 16-SOIC (0.154", 3.90mm Width)
Manufacturer Package 16-SO
Win Source Part Number 704093-MAX4665ESE+T
Series MAX series
Family Name MAX4665
Introduction Date July 01, 1999
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX4665ESE+T CAD Model

Description

Maxim Integrated MAX4665ESE+T Analog Switch

The Maxim Integrated MAX4665ESE+T is a high-performance, quad SPST (single-pole single-throw) analog switch that offers a perfect solution for precision analog signal switching. This component is designed for applications that require low on-resistance, low leakage currents, and fast switching times. The MAX4665ESE+T is well-suited for use in a variety of systems, including communication devices, data acquisition systems, and audio/visual equipment.

Encased in a compact 16-pin SOIC package, the MAX4665ESE+T operates over a wide voltage range of ±4.5V to ±20V, or a single supply voltage of +9V to +36V, making it versatile for diverse operating environments. This flexibility allows designers to integrate the switch into both bipolar and unipolar power supply systems with ease.

One of the standout features of the MAX4665ESE+T is its low on-resistance, typically just 100Ω, which ensures minimal signal distortion and power loss across the switch. Additionally, the device boasts low charge injection, which minimizes the impact on signal integrity during switching events, a critical consideration for precision applications.

The MAX4665ESE+T also features fast switching speeds, with turn-on and turn-off times typically around 175ns and 145ns, respectively. This rapid performance is essential for applications that require quick response times and high throughput. Moreover, the device's low power consumption makes it an excellent choice for battery-powered and portable applications where energy efficiency is paramount.

For enhanced reliability, the MAX4665ESE+T includes built-in ESD protection, safeguarding the device from electrostatic discharges that can occur during handling or operation. This protection helps to ensure a longer operational lifespan and reduces the likelihood of failure in sensitive electronic equipment.

In summary, the Maxim Integrated MAX4665ESE+T analog switch is a highly reliable and efficient solution for designers who require a high-quality switch with excellent electrical characteristics. Its robust feature set and operational flexibility make it an ideal choice for a wide range of applications that demand precision and performance.
