Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 70mV
Data Rate 250kbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 091141-MAX487CSA
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX487CSA CAD Model

Description

The MAX487CSA from Maxim Integrated is a high-performance, low-power transceiver for RS-485 and RS-422 communication, encapsulated in an 8-pin SOIC package. This device is designed to provide reliable data transmission over long distances and in electrically noisy environments. It is particularly suitable for industrial applications, such as factory automation, process control, and other situations where a robust communication link is required.

Key Features

  • Low Quiescent Current: The MAX487CSA operates with a very low supply current, typically 300µA, making it ideal for power-sensitive applications.
  • Slew-Rate Limiting: This feature minimizes electromagnetic interference (EMI) and reduces reflections caused by improperly terminated cables, allowing for error-free data transmission at rates up to 2.5Mbps.
  • Half-Duplex Communication: The transceiver supports bidirectional communication on a single twisted-pair, simplifying network topologies and reducing cable costs.
  • Extended Temperature Range: The device operates reliably over a wide temperature range from -40°C to +85°C, ensuring performance in harsh environments.
  • Fail-Safe Receiver: Even when the input is shorted or open, or the data lines are idle, the receiver output remains in a high state, preventing false data transmission.
  • Thermal Shutdown: The built-in thermal shutdown feature protects the device from damage due to excessive power dissipation.

Applications

The MAX487CSA transceiver is versatile and can be used in various applications, including:

  • Industrial Control Systems
  • Building Automation
  • Networked Security Systems
  • Data Collection Devices
  • Remote Sensors

Conclusion

Maxim Integrated's MAX487CSA is a robust and reliable solution for RS-485/RS-422 communication, offering features such as low power consumption, slew-rate limiting, and an extended operational temperature range. Its fail-safe receiver and thermal shutdown capabilities make it a secure choice for critical applications where dependable data transmission is a must.
