Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 70mV
Data Rate 250kbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 021805-MAX488CSA+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX488CSA+ CAD Model

Description

Product Overview: MAX488CSA+ from Maxim Integrated

The MAX488CSA+ is a robust and highly reliable low-power transceiver module for RS-485 and RS-422 communication from Maxim Integrated. This transceiver is designed to provide bidirectional data communications on multipoint bus transmission lines. It is an essential component for applications requiring high-speed, balanced transmission lines and is widely used in industrial, network, and automation systems.

Key Features

  • Interface Type: RS-485/RS-422, which allows for balanced data transmission and reception, ensuring robust communication in electrically noisy environments.
  • Supply Voltage Range: 4.75V to 5.25V, making it suitable for use with standard 5V power supplies.
  • Low Quiescent Current: 300µA, which is ideal for power-sensitive applications.
  • High Data Rates: Capable of up to 2.5Mbps, allowing for fast data transfer.
  • Extended Temperature Range: -40°C to +85°C, ensuring reliable operation under various environmental conditions.
  • Fail-Safe Receiver: Guarantees a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with all transmitters disabled.
  • True Fail-Safe Receiver: Prevents false transitions on the receiver output that could otherwise occur with a traditional fail-safe feature.
  • ESD Protection: ±15kV Human Body Model (HBM) on the transceiver's bus pins, providing robust protection against electrostatic discharge.

Applications

The MAX488CSA+ is versatile and can be used in a variety of applications, including:

  • Industrial Control Systems
  • Building Automation
  • Networked Security Systems
  • Data Acquisition Systems
  • Remote Sensors

Package and Quality

The transceiver comes in a space-saving 8-pin SOIC package, which is suitable for compact designs. Maxim Integrated ensures high-quality standards, and the MAX488CSA+ is no exception. It undergoes rigorous testing to guarantee performance and reliability.

In conclusion, the MAX488CSA+ transceiver from Maxim Integrated is a high-performance solution for RS-485/RS-422 communication, offering a combination of speed, power efficiency, and robustness, making it a top choice for designers and engineers in various industries.
