Maxim Integrated MAX491ESD+T Low-Power, Slew-Rate-Limited RS-485/RS-422 Transceivers

The Maxim Integrated MAX491ESD+T transceiver is designed to provide reliable communication for RS-485 and RS-422 data networks. This integrated circuit is specifically engineered to operate in environments where low power consumption and electromagnetic interference (EMI) are of concern. The device features a slew-rate-limited driver which minimizes EMI and reduces reflections caused by improperly terminated cables, making it ideal for long-distance data transmission in industrial applications.

The transceiver operates from a single 5V supply and has a fully compliant EIA/TIA-485 communication standard. It is capable of differential communication on bus networks of up to 32 devices over a maximum cable length of 4000 feet (approximately 1200 meters). The MAX491ESD+T is designed with driver output and receiver input protection against ±15kV electrostatic discharge (ESD) shocks, which enhances its robustness and reliability in harsh industrial environments.

With a low quiescent current of typically 300μA, the MAX491ESD+T is an excellent choice for energy-sensitive applications. Furthermore, it features a 1/4-unit-load receiver input impedance, allowing up to 128 devices on the bus. The device also includes thermal shutdown and short-circuit protection, which prevents damage to the transceiver under fault conditions.

The MAX491ESD+T is available in a narrow 14-pin SO package, making it a space-saving solution for compact designs. Its operating temperature range of -40°C to +85°C ensures reliable performance in a wide range of environmental conditions. This transceiver is suitable for a variety of applications, including industrial control systems, networked security systems, building automation, and any other applications requiring robust data communication with controlled signal dynamics.

Overall, the Maxim Integrated MAX491ESD+T transceiver is a high-performance solution that combines durability, low-power operation, and protection features to meet the stringent requirements of modern industrial communication systems.
