Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Features Series, Buried Zener Voltage Reference IC Fixed 2.5V V ±0.04% 15 mA 8-SOIC
Manufacturer Maxim Integrated
Package Tube
Part Status Obsolete
Operating Temperature Range 0°C ~ 70°C (TA)
Mounting Surface Mount
Package 8-SOIC (0.154", 3.90mm Width)
Case / Package 8-SOIC
Family Name MAX6325
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Quantity per package 1
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 882188-MAX6325CSA
Ultra Librarian 3D Model Ultra Librarian MAX6325CSA CAD Model

Description

Maxim Integrated MAX6325CSA Precision Voltage Reference

The MAX6325CSA from Maxim Integrated is a high-precision voltage reference that offers a low dropout voltage and excellent temperature stability. Designed for applications requiring a stable reference voltage over a wide temperature range, the MAX6325CSA is ideal for high-resolution analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and other precision circuitry.

This device is available in an 8-pin SOIC package, making it suitable for space-constrained applications. It features a series reference architecture, and the output voltage is preset at the factory with multiple options available to cater to various application needs. The MAX6325CSA provides a fixed output voltage of 2.5V, which is maintained with a tight accuracy over the operating temperature range.

One of the key features of the MAX6325CSA is its impressive temperature coefficient, typically just 3ppm/°C, ensuring minimal deviation in output voltage with changes in ambient temperature. This makes it an excellent choice for systems that operate in environments with fluctuating temperatures and require consistent performance.

The device also boasts a low dropout voltage, meaning it can maintain a stable output even when the supply voltage is close to the output voltage. This characteristic is essential for battery-powered devices where the supply voltage may vary over time. Additionally, the MAX6325CSA has a low supply current, further enhancing its suitability for portable and low-power applications.

For enhanced stability, the MAX6325CSA incorporates a force and sense terminal that allows for remote voltage sensing, compensating for voltage drops in the power supply lines. It also features a high load-driving capability, able to source or sink up to 15mA of load current, and it maintains a low output noise, contributing to overall system precision.

With its combination of high accuracy, low power consumption, and robust temperature performance, the Maxim Integrated MAX6325CSA is a reliable and versatile choice for precision voltage reference applications across a diverse range of industries.
