Maxim Integrated MAX9709ETN+TD Class D Audio Amplifier

The MAX9709ETN+TD from Maxim Integrated is a high-performance, single-chip Class D audio amplifier that offers a combination of low power consumption and high efficiency, making it an ideal solution for portable and space-constrained applications. This integrated circuit is designed to deliver exceptional sound quality with a high level of audio fidelity.

The MAX9709ETN+TD operates over a wide supply voltage range from 8V to 28V, which allows for flexible usage in various system designs. Its high efficiency of up to 92% ensures that the device generates minimal heat, thus reducing the need for bulky heat sinks and allowing for a more compact overall design.

This audio amplifier is capable of delivering up to 2 x 15W into a 4Ω load or 2 x 10W into an 8Ω load with less than 0.1% THD+N, ensuring robust and clear audio output. The device features a fully differential architecture that minimizes common-mode noise and provides excellent power supply rejection, further enhancing the audio performance.

The MAX9709ETN+TD is equipped with built-in protection features, including over-temperature protection, under-voltage lockout, and short-circuit protection, which contribute to the reliability and longevity of the amplifier. Additionally, it includes a mute function that allows the user to turn off the audio output without powering down the entire system.

The device comes in a 56-pin thin QFN (TQFN) package, which is not only space-saving but also offers enhanced thermal performance. The MAX9709ETN+TD is suitable for a wide range of applications such as LCD TVs, digital photo frames, docking stations, and any other system that requires a small footprint, high-quality audio amplifier.

Overall, the Maxim Integrated MAX9709ETN+TD Class D audio amplifier is a versatile and efficient solution for modern audio applications, combining high output power, excellent audio quality, and a range of protective features in a compact package.
