SS210B Rugao Dachang Electronics Co., Ltd
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMB
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 850 mV @ 2 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 100 V
Capacitance @ Vr, F 180pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB
Operating Temperature - Junction -55°C ~ 150°C
Standard Package 6,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 676280-SS210B
Ultra Librarian 3D Model Ultra Librarian SS210B CAD Model

Description

The 676280-SS210B is a fast recovery Schottky diode designed for rectifier applications.

  • Maximum Reverse Voltage: 100V
  • Average Rectified Current: 2A
  • Forward Voltage Drop: 850mV @ 2A
  • Recovery Time: Less than 500ns
  • Package: DO-214AA, SMB
  • Capacitance: 180pF @ 4V and 1MHz
  • Junction Temperature Range: -55°C to 150°C
  • Product Category: Discrete Semiconductor Products
  • Application: Rectification
