NES-100-24 Mean Well Enterprises Co., Ltd.
Same model may have multiple batches, images only for reference.

NES-100-24

Part No NES-100-24
Manufacturer Mean Well Enterprises Co., Ltd.
Catalog External/Internal (Off - Board) AC DC Converters
Description AC/DC CONVERTER 24V 108W
Datasheet
NES-100-24 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board) - AC DC Converters
Mfr Mean Well Enterprises Co., Ltd.
Series NES-100 (100W)
Package Box
Product Status Obsolete
Type Enclosed
Number of Outputs 1
Voltage - Input 85 ~ 132 VAC, 176 ~ 264 VAC, 248 ~ 373 VDC
Voltage - Output 1 24V
Current - Output 1 4.5 A
Power (Watts) 108W
Applications ITE (Commercial)
Voltage - Isolation 3 kV
Efficiency 86%
Temperature Range - Operating -20°C ~ 60°C (With Derating)
Features Adjustable Output
Mounting Type Chassis Mount
Size / Dimension 6.26" L x 3.82" W x 1.50" H (159.0mm x 97.0mm x 38.0mm)
Approval Agency CB, CCC, CE, cURus
Minimum Load Required No
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9520
Win Source Part Number 648392-NES-100-24
Ultra Librarian 3D Model Ultra Librarian NES-100-24 CAD Model

Description

The NES-100-24 is a 100W enclosed AC-DC converter manufactured by Mean Well Enterprises Co., Ltd.

  • Series: NES-100
  • Output Voltage: 24V
  • Size: 6.26" L x 3.82" W x 1.50" H
  • Mounting: Chassis
  • Efficiency: 86%
  • Safety Standards: CB, CCC, CE, cURus
  • Status: Obsolete
  • Application: Commercial
