SMBJ5339B-TP

Name: SMBJ5339B-TP
Brand: Micro Commercial Co
SKU: 514582
Availability: InStock
Rating: 4.91 (369 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMBJ5339B-TP
Manufacturer	Micro Commercial Co
Catalog	Diodes - Zener - Single
Description	Zener Diode Single 5.6V 5% 1Ohm 5000mW 2-Pin SMB T/R / DIODE ZENER 5.6V 5W DO214AA
Datasheet	SMBJ5339B-TP Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Micro Commercial Co
Packaging	Reel - TR
Status	Active
Voltage - Zener (Nom) (Vz)	5.6V
Tolerance	±5%
Maximum Power Dissipation	5W
Impedance (Max) (Zzt)	1 Ohm
Current - Reverse Leakage @ Vr	1μA @ 2V
Voltage - Forward (Vf) (Max) @ If	1.2V @ 1A
Temperature Range - Operating	-55°C to 150°C
Mounting	SMD (SMT)
Case / Package	DO-214AA (SMB)
Win Source Part Number	1097808-SMBJ5339B-TP
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Quantity per package	3k pcs
Family Name	SMBJ5339B
Introduction Date	June 26, 1997
ECCN	EAR99
Country of Origin	China, Taiwan
Halogen Free	Compliant
Estimated EOL Date	2025
Ultra Librarian 3D Model	Ultra Librarian SMBJ5339B-TP CAD Model

Alternative Products

Description

It has a limited supply and demand status. This component has been manufactured by Micro Commercial Co and has a Win Source Part Number of 1097808-SMBJ5339B-TP.

Package: DO-214AA (SMB)
Mounting: SMD
Tolerance: ±5%
Voltage - Forward (Vf) (Max) @ If: 1.2V @ 1A
Current - Reverse Leakage @ Vr: 1μA @ 2V
Voltage - Zener (Nom) (Vz): 5.6V
Impedance (Max) (Zzt): 1 Ohm
Family: Discrete Semiconductor Products
Halogen Free: Compliant
Status: Common-used Part
