Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - Microcontrollers
Mfr Microchip Technology
Series AVR® ATmega, Functional Safety (FuSa)
Package Tape & Reel
Core Processor AVR
Core Size 8-Bit
Speed 20MHz
Connectivity I2C, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 27
Program Memory Size 32KB (16K x 16)
Program Memory Type FLASH
EEPROM Size 1K x 8
RAM Size 2K x 8
Supply Voltage - Operating 1.8V ~ 5.5V
Data Converters A/D 8x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 32-VFQFN Exposed Pad
Supplier Device Package 32-VFQFN (5x5)
Base Product Number ATMEGA328
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Other Names ATMEGA328PB-MUR-ND,ATMEGA328PB-MURCT,ATMEGA328PB-MURDKR,ATMEGA328PB-MURTR
Standard Package 6,000
Win Source Part Number 969703-ATMEGA328PB-MUR
Ultra Librarian 3D Model Ultra Librarian ATMEGA328PB-MUR CAD Model

Description

Microchip Technology's ATMEGA328PB-MUR: A Versatile Microcontroller for Advanced Projects

The ATMEGA328PB-MUR from Microchip Technology is a powerful microcontroller that builds upon the success of the well-known ATmega328 series. This high-performance, low-power AVR® 8-bit MCU combines 32KB ISP flash memory, 1KB EEPROM, 2KB SRAM, 24 general purpose I/O lines, 32 general registers, three flexible timer/counters with compare modes, internal and external interrupts, a serial programmable USART, a byte-oriented 2-wire serial interface, SPI serial port, a 6-channel/8-channel 10-bit A/D converter (a 6-channel in TQFP and QFN/MLF packages and 8-channel in PDIP package), programmable watchdog timer with internal oscillator, and five software selectable power saving modes.

Designed to operate between 1.8-5.5 volts, it is suitable for a wide range of applications in the industrial, automotive, and consumer electronics markets. The device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed.

One of the notable enhancements of the ATMEGA328PB-MUR over its predecessors is the inclusion of two additional 16-bit timer/counters, two additional serial communication interfaces, and a touch interface for capacitive buttons, sliders, and wheels. The extra hardware serial ports facilitate easier communication with multiple external devices simultaneously, while the touch interface adds a modern touch control option to the user interface design.

The ATMEGA328PB-MUR is available in a 32-lead TQFP and 28-lead PDIP, making it a versatile choice for projects that require a compact form factor without sacrificing input/output (I/O) options. It is ideal for applications requiring complex and multiple tasks, such as advanced control systems, Internet-of-Things (IoT) devices, sensor networks, and many other embedded system applications.

With its robust feature set and flexibility, the ATMEGA328PB-MUR is a go-to microcontroller for engineers and hobbyists alike looking to push the boundaries of what's possible with microcontroller technology. Whether you're designing a smart home device, an industrial control system, or a new interactive gadget, the ATMEGA328PB-MUR provides a reliable foundation for your innovation.

For detailed technical specifications, application notes, and support resources, visit Microchip Technology's official website or consult the ATMEGA328PB-MUR datasheet.
