Products specifications

Manufacturer Microchip Technology
Packaging Tray
Core Processor AVR
Core Size 8-Bit
Speed 16MHz
Connectivity SPI, UART/USART, USB
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 22
Program Memory Size 8KB (4K x 16)
Program Memory Type FLASH
EEPROM Size 512 x 8
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 2.7V ~ 5.5V
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 32-TQFP
Supplier Device Package 32-TQFP (7x7)
Part Number Series ATMEGA8U2
Manufacturer Pack Quantity 250
MSL Level 3 (168 Hours)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 811514-ATMEGA8U2-AU
Ultra Librarian 3D Model Ultra Librarian ATMEGA8U2-AU CAD Model

Description

Microchip Technology's ATMEGA8U2-AU Microcontroller

The ATMEGA8U2-AU is a versatile and high-performance microcontroller from Microchip Technology, designed to cater to a wide array of applications ranging from consumer electronics to industrial automation. This device is part of Microchip's popular AVR® microcontroller series, which is renowned for its user-friendly architecture and efficient operation.

At the heart of the ATMEGA8U2-AU is an advanced 8-bit AVR RISC-based microcontroller that operates at up to 16MHz. It is equipped with 8KB of in-system self-programmable flash memory, 512B EEPROM, and 512B SRAM. These memory options provide ample space for code and data storage, allowing developers to create complex and robust applications without worrying about space constraints.

The microcontroller boasts a wide range of features that enhance its functionality and ease of use. It includes a USB 2.0 Full-speed/Low Speed Device Module, which enables seamless integration with USB-based devices and systems. The module is designed for USB connectivity and is compliant with USB 2.0 specifications, ensuring reliable data transfer and communication.

Furthermore, the ATMEGA8U2-AU offers various peripherals that expand its capabilities, such as an 10-bit Analog-to-Digital Converter (ADC) with up to 12 channels, allowing for precise analog signal measurement. It also has a programmable Watchdog Timer with internal oscillator, ensuring system stability and reliability.

For communication, this microcontroller supports serial USART, SPI, and Two-Wire Serial Interface (TWI/I2C) protocols, enabling it to interface with a wide range of sensors, actuators, and other microcontrollers. The device also features Power-on Reset and Programmable Brown-out Detection, which contribute to its robust operation in unpredictable power environments.

Designed with power efficiency in mind, the ATMEGA8U2-AU supports multiple power-saving modes, making it suitable for battery-operated and portable applications. Its compact TQFP (Thin Quad Flat Pack) 32-pin package allows for a small footprint on printed circuit boards, which is essential for space-constrained designs.

In summary, the ATMEGA8U2-AU from Microchip Technology is a powerful and flexible microcontroller that offers an optimal balance between performance, power consumption, and peripheral integration, making it an excellent choice for a broad range of electronic applications.
