The DSC1001DL5-012.2880T is a state-of-the-art silicon MEMS oscillator from Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This high-performance device is designed to offer a reliable and precise clocking solution for a wide range of applications, including industrial, automotive, consumer electronics, and communication systems.

Key Features

• Frequency: The oscillator operates at a fixed frequency of 12.2880 MHz, which is a common clock rate used in digital audio applications and other high-speed digital signal processing (DSP) systems.
• Package: Housed in a compact 6-pin DFN (Dual Flat No-Lead) package, the DSC1001DL5-012.2880T is designed for space-constrained applications. The package dimensions are 3.2 x 2.5 mm (L x W).
• Stability: Offers excellent frequency stability over a wide temperature range, ensuring consistent performance and reliability in varying environmental conditions.
• Supply Voltage: Designed to operate at a supply voltage of 1.8V to 3.3V, the device caters to low-power applications and supports a variety of design requirements.
• Output Type: The oscillator provides a CMOS/LVCMOS-compatible output, making it easily integrable with a broad range of digital circuits.
• Low Jitter: The DSC1001DL5-012.2880T boasts low phase jitter, which is critical for high-speed communication interfaces and ensures minimal signal interference.

Applications

The versatility of the DSC1001DL5-012.2880T makes it suitable for numerous applications, including but not limited to:

• High-definition audio and video equipment
• Networking gear such as routers, switches, and network interface cards
• Wireless communication devices
• Industrial control systems
• Automotive electronics

Quality and Reliability

Microchip Technology is committed to delivering products that meet the highest standards of quality and reliability. The DSC1001DL5-012.2880T is no exception, providing a robust clocking solution that engineers can trust for their critical applications.
