Products specifications

Category Discrete Semiconductor Products>Transistors>Bipolar (BJT)>Single Bipolar Transistors
Mfr Microchip Technology
Series Military, MIL-PRF-19500/396
Package Bulk
Transistor Type PNP
Current - Collector (Ic) (Max) 1.5 A
Voltage - Collector Emitter Breakdown (Max) 40 V
Vce Saturation (Max) @ Ib, Ic 900mV @ 100mA, 1A
Current - Collector Cutoff (Max) 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 1A, 1.5V
Power - Max 1 W
Frequency - Transition -
Temperature Range - Operating -55°C ~ 200°C (TJ)
Mounting Type Through Hole
Package / Case TO-205AD, TO-39-3 Metal Can
Supplier Device Package TO-39 (TO-205AD)
Base Product Number 2N3762
RoHS Status RoHS non-compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Standard Package 1 pcs
Win Source Part Number 1382394-JAN2N3762
Ultra Librarian 3D Model Ultra Librarian JAN2N3762 CAD Model

Description

The JAN2N3762 is a high-quality NPN bipolar junction transistor (BJT) developed by Microchip Technology, a leader in the field of microcontroller and analog semiconductors. Designed to meet the stringent requirements of the aerospace industry, this transistor is part of the JAN (Joint Army Navy) series, which signifies that it has been manufactured and tested to meet the military standards for electronic components.

Key Features

  • High Reliability: The JAN2N3762 is built to withstand extreme environmental conditions, making it suitable for use in military and aerospace applications where reliability is of utmost importance.
  • Power Handling: This device is capable of handling significant power levels, with a collector-emitter voltage (VCEO) of 60V and a collector power dissipation of up to 5W, making it ideal for power amplification and switching applications.
  • Robust Performance: With a collector current (IC) rating of up to 10A, the JAN2N3762 can drive high current loads, offering robust performance in demanding circuits.
  • Hermetic Packaging: The transistor is encapsulated in a hermetically sealed package, ensuring protection against moisture and contaminants, which is critical for the longevity and reliability of the component in harsh environments.

Applications

The JAN2N3762 is versatile and can be used in a wide range of applications. Its high reliability and power handling capabilities make it particularly well-suited for:

  • Power supply regulators
  • High-speed switching circuits
  • Linear amplifiers
  • Motor controllers
  • Other military and aerospace electronic systems

Quality Assurance

Microchip Technology ensures that each JAN2N3762 transistor meets the rigorous standards required for military applications. The components undergo comprehensive testing and quality control procedures, which include screening for operation at various temperatures, verifying electrical parameters, and ensuring long-term reliability. This meticulous approach to quality assurance means that customers can trust the performance and durability of the JAN2N3762 in their critical applications.
