Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tray
Status Active
Protocol Ethernet
Purpose Controller
Standards 10/100 Base-T/TX PHY
Supply Voltage - Operating 3.3V
Operating Supply Current 100mA
Temperature Range - Operating 0°C to 85°C
Case / Package 128-QFP
Win Source Part Number 205961-LAN91C113-NS
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LAN91C113-NS CAD Model

Description

Microchip Technology's LAN91C113-NS is a highly integrated Ethernet controller designed for embedded systems requiring network connectivity. This robust controller is a perfect solution for applications in industrial automation, home networking, and other network-enabled devices.

Key Features

  • Network Standards: Fully compliant with IEEE 802.3/802.3u standards, ensuring compatibility with a wide range of network devices and systems.
  • Interface Options: Features a Non-PCI interface for versatile connectivity with various microcontrollers and processors.
  • Memory Management: Integrated 32 KB SRAM for frame buffering reduces the need for external memory components, which simplifies design and reduces system costs.
  • Advanced Packet Processing: Supports full-duplex and half-duplex operation with hardware-assisted checksum calculation for enhanced data integrity.
  • Power Management: Includes power-saving features that enable energy-efficient operation, making it suitable for power-sensitive applications.

Performance and Reliability

The LAN91C113-NS is designed for high-performance networking with a dedicated DMA engine that facilitates fast data transfers while minimizing CPU load. Its reliable operation is backed by Microchip's commitment to quality, ensuring long-term performance in demanding environments.

Easy Integration

With its comprehensive feature set and ease of integration, the LAN91C113-NS is an ideal choice for designers looking to add networking capabilities to their products without significant redesign efforts. The controller is available in a space-saving 128-pin QFP package, which is suitable for compact PCB layouts.

Support and Resources

Microchip Technology provides extensive support for the LAN91C113-NS with detailed datasheets, application notes, and design guides. Developers can also access Microchip's technical support services to assist with integration, development, and troubleshooting.
