Microchip Technology MCP1702T-2502E/CB Low Dropout Voltage Regulator

The MCP1702T-2502E/CB is a high-performance, low-dropout voltage regulator from Microchip Technology, designed to deliver a fixed output voltage of 2.5V with an input voltage range from 2.7V to 13.2V. This component is ideal for battery-powered devices, due to its low quiescent current of only 2 µA, which helps to extend battery life. The MCP1702T-2502E/CB is available in a small, 3-pin SOT-23A package, making it suitable for space-constrained applications.

With its ability to supply up to 250 mA of output current, this voltage regulator is a reliable choice for low-power applications such as microcontrollers, analog circuits, and portable electronic devices. The MCP1702T-2502E/CB features thermal overload protection and short-circuit current limiting, ensuring stable performance and protection for your electronic circuits.

Key Features:

• Output Voltage: Fixed 2.5V output to power a wide range of devices.
• Input Voltage Range: 2.7V to 13.2V, compatible with multiple power sources.
• Low Quiescent Current: Only 2 µA, minimizing power consumption when idle.
• Output Current: Capable of supplying up to 250 mA.
• Low Dropout Voltage: Ensures efficient operation, even with very low voltage differences between input and output.
• Protection Features: Includes thermal overload protection and short-circuit current limiting.
• Package Type: Available in a compact SOT-23A package.
• Stable with Ceramic Output Capacitors: Can be used with low-cost, space-saving ceramic capacitors.
• Temperature Range: Industrial temperature range from -40°C to +125°C.

The MCP1702T-2502E/CB is a testament to Microchip Technology's commitment to providing high-quality power management solutions. With its robust feature set and compact form factor, it is an excellent choice for engineers and designers looking to optimize their power-sensitive applications.
