Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Microchip Technology
Packaging Tube
Number of I/O 16
Interface I2C
Interrupt Output Yes
Features POR
Output Type Open Drain
Current - Output Source/Sink 25mA
Clock Frequency 3.4MHz
Operating Supply Voltage 1.8 V ~ 5.5 V
Operating Temperature Range -40°C ~ 125°C
Mounting SMD
Package 28-SOIC (0.295", 7.50mm Width)
Manufacturer Package 28-SOIC
Win Source Part Number 1221017-MCP23018-E/SO
Manufacturer Homepage www.microchip.com
Popularity Medium
Supply and Demand Status Limited
Family Name MCP23018
Introduction Date September 29, 2008
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian MCP23018-E/SO CAD Model

Description

Microchip Technology MCP23018-E/SO

The MCP23018-E/SO is a robust integrated circuit from Microchip Technology, renowned for its high performance and reliability in various applications. This 16-bit I/O expander with serial interface is designed to provide a simple solution for expanding I/O capabilities using the two-wire I²C-compatible serial interface. The device comes in a convenient SOIC-28 package, which is suitable for surface-mount technology, making it ideal for space-constrained applications.

With its extensive feature set, the MCP23018-E/SO addresses the needs of systems that require additional I/Os. The device features high-speed I²C interface with up to 1.7 MHz clock speed, enabling quick communication with microcontrollers. Additionally, it supports both 7-bit and 10-bit addressing, which allows for a flexible address scheme and the possibility to use multiple devices on the same bus.

The MCP23018-E/SO provides 16 GPIO pins, which can be individually set to inputs or outputs, giving designers the freedom to configure the device according to their specific needs. Each I/O pin is also equipped with internal pull-up resistors, interrupt-on-change, and default value registers, enhancing the device's versatility and reducing the need for external components.

One of the key features of this I/O expander is its interrupt output, which can be configured to alert the host microcontroller when an input state changes, thus reducing the need for constant polling and enabling more efficient power management in battery-operated devices. The open-drain configuration of the interrupt output allows for the wired-AND connection of multiple devices, simplifying system design.

The MCP23018-E/SO operates over a broad voltage range of 1.8V to 5.5V, making it suitable for both low-voltage and standard applications. Its robust design ensures stable operation across the industrial temperature range of -40°C to +125°C.

In summary, the MCP23018-E/SO from Microchip Technology is an ideal choice for designers looking to enhance their system's I/O capabilities without significantly increasing the complexity or size of their design. Its mix of flexibility, performance, and ease-of-use makes it a valuable component in applications such as industrial control, home automation, and any other system requiring additional I/Os.
