Products specifications Report Issue?

Category Integrated Circuits (ICs)>Interface - Sensor and Detector Interfaces
Mfr Microchip Technology
Package Tube
Type Thermocouple to Digital Converter
Input Type Thermocouple
Output Type I2C
Current - Supply 300 µA
Temperature Range - Operating -40°C ~ 125°C
Mounting SMD (SMT)
Package / Case 20-VQFN Exposed Pad
Supplier Device Package 20-MQFN (5x5)
Base Product Number MCP9600
Standard Package 73
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1261015-MCP9600-E/MX
Ultra Librarian 3D Model Ultra Librarian MCP9600-E/MX CAD Model

Description

MCP9600-E/MX Thermocouple IC

The MCP9600-E/MX is a sophisticated thermocouple-to-digital converter manufactured by Microchip Technology, which integrates an array of features to facilitate high-precision temperature measurement. This advanced integrated circuit (IC) is designed to work with any thermocouple type, making it a versatile solution for a wide range of temperature sensing applications.

Equipped with an integrated cold-junction compensation, the MCP9600-E/MX offers a digital representation of the thermocouple’s temperature and eliminates the need for additional components to correct for varying ambient temperatures. The device is capable of detecting temperature differences as small as 0.1°C and features a temperature range that depends on the thermocouple used, with precision accuracy.

One of the key benefits of the MCP9600-E/MX is its user-programmable registers that allow fine-tuning of the temperature sensing parameters. These registers control features such as thermocouple type selection, filter coefficient, and temperature alert limits. This level of customization ensures that the IC can be tailored to meet the specific needs of the application it is being used in.

The MCP9600-E/MX supports I2C communication, providing an easy interface with microcontrollers or other I2C-compatible devices. This allows for straightforward integration into existing systems and simplifies the process of retrieving temperature data. The IC also includes four user-programmable temperature alert outputs, which can be configured to trigger on temperature thresholds, adding to its versatility.

Available in a compact 20-pin QFN package, the MCP9600-E/MX is suitable for space-constrained applications. It operates over a supply voltage range of 2.7V to 5.5V, making it compatible with most common electronic systems. With its robust feature set and flexibility, the MCP9600-E/MX is an ideal choice for applications in industrial, automotive, and consumer electronics where precise temperature monitoring is crucial.
