Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Core Processor PIC
Part Core Size 8-Bit
Speed(Frequency) 20MHz
Number of I/O 5
Program Memory Size 3.5KB (2K x 14)
Program Memory Type FLASH
EEPROM Size 256 x 8
Data RAM Size 128 x 8
Supply Voltage - Operating 2 V to 5.5 V
Data Converters A/D 4x10b
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 8-SOIC
Win Source Part Number 210012-PIC12F683T-E/SN
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Automotive, Automotive, Consumer Electronics, Motor Drive & Control, Lighting, Medical, Security
Ultra Librarian 3D Model Ultra Librarian PIC12F683T-E/SN CAD Model

Description

Microchip Technology PIC12F683T-E/SN Microcontroller

The PIC12F683T-E/SN is a high-performance microcontroller unit (MCU) from Microchip Technology, renowned for its compact design, versatility, and power efficiency. This 8-bit microcontroller is based on Microchip's advanced RISC architecture, offering a perfect solution for a wide range of embedded applications.

Encased in an 8-pin SOIC package, the PIC12F683T-E/SN operates within an extended temperature range, making it suitable for industrial and automotive applications where reliability under harsh conditions is paramount. The device features 3.5KB of flash memory, providing ample space for application code, and 256 bytes of RAM for data processing and storage. Additionally, it boasts 128 bytes of EEPROM, which allows for non-volatile storage of critical data that must be preserved across power cycles.

This MCU is equipped with an array of integrated peripherals that enhance its functionality without the need for additional components. These include a 10-bit Analog-to-Digital Converter (ADC), which enables the microcontroller to interface with analog sensors and devices. It also offers two Comparators, a PWM module, and a versatile 8-bit timer, as well as a Timer1 module that can be used as a 16-bit timer/counter.

One of the key features of the PIC12F683T-E/SN is its Enhanced Capture/Compare/PWM (ECCP) functionality, providing advanced control for a variety of applications, such as motor control and LED dimming. The microcontroller also supports In-Circuit Serial Programming (ICSP) and In-Circuit Debugging (ICD), facilitating easy development, programming, and debugging.

With its integrated oscillator and Power-on Reset (POR), Brown-out Reset (BOR), and Watchdog Timer (WDT) safety features, the PIC12F683T-E/SN ensures reliable operation, safeguarding against system failures due to unstable power supply or unintended software behavior.

Overall, the PIC12F683T-E/SN from Microchip Technology is an ideal choice for designers seeking a robust, feature-rich microcontroller for applications ranging from simple consumer gadgets to complex automotive systems. Its balance of power, size, and integrated features make it an efficient and cost-effective solution for a multitude of embedded design projects.
